Note: Data may vary by configuration. See CONFIGURATION section.
| Cavity |
T-5A |
| Series |
2 |
| Capacity |
12 gpm45 L/min. |
| Maximum Operating Pressure |
5000 psi350 bar |
| Valve Hex Size |
1 1/8 in.28,6 mm |
| Valve Installation Torque |
45 - 50 lbf ft61 - 68 Nm |
| Adjustment Screw Internal Hex Size |
5/32 in.4 mm |
| Locknut Hex Size |
9/16 in.15 mm |
| Locknut Torque |
80 - 90 lbf in.9 - 10 Nm |
| Model Weight |
.40 lb0,20 kg |
| Seal kit - Cartridge |
Buna: 990203007 |
| Seal kit - Cartridge |
EPDM: 990203014 |
| Seal kit - Cartridge |
Viton: 990203006 |
