Note: Data may vary by configuration. See CONFIGURATION section.
| Cavity |
T-18A |
| Series |
4 |
| Capacity |
50 gpm200 L/min. |
| Maximum Operating Pressure |
5000 psi350 bar |
| Valve Hex Size |
1 5/8 in.41,3 mm |
| Valve Installation Torque |
350 - 375 lbf ft474 - 508 Nm |
| Adjustment Screw Internal Hex Size |
5/32 in.4 mm |
| Locknut Hex Size |
9/16 in.15 mm |
| Locknut Torque |
80 - 90 lbf in.9 - 10 Nm |
| Model Weight |
1.00 lb0,45 kg |
| Seal kit - Cartridge |
Buna: 990018007 |
| Seal kit - Cartridge |
Polyurethane: 990018002 |
| Seal kit - Cartridge |
Viton: 990018006 |
