PV7-1X/06-10RA01MA0-10

Fiyat : $35.38(KDV Dahil)

R900563233

:

Rexroth P7 Variable Displacement Vane Pumps


High reliability. Low noise and low pulsation level. High efficiency. Quick response behavior of the controller.


Product attributes

Displacement type

variable

Size [cm³]

10

Max. pressure [bar]

50

Max. flow [l/min]

18

Through-drive

without

Direction of rotation

clockwise rotation

Shaft end

Cylindrical Ø 20 mm with fitting key, ISO 3019-2

Fastening

4-hole mounting flange 80B4HW according to ISO 3019-2

Hydraulic fluid

HLP,HLPD,HVLP,HVLPD

Seals

NBR

Weight [kg]

5.12

Document type Download link
Datasheets 8c0483e6-c96e-4a82-b6aa-b76379199160
Download link
3D CAD
