PVDA8WN

Fiyat : $127.91

Pilot-operated, pressure reducing/relieving main stage with integral T-8A control cavity and drain to port 4

:
PVDA8

Note: Data may vary by configuration. See CONFIGURATION section.
Cavity T-21A
Series 1
Capacity 10 gpm40 L/min.
Maximum Operating Pressure 5000 psi350 bar
Control Pilot Flow 7 - 10 in³/min.0,11 - 0,16 L/min.
Pilot Control Cavity T-8AT-8A
Valve Hex Size 7/8 in.22,2 mm
Valve Installation Torque 30 - 35 lbf ft41 - 47 Nm
Model Weight .30 lb0,15 kg
Seal kit - Cartridge Buna: 990021007
Seal kit - Cartridge Polyurethane: 990021002
Seal kit - Cartridge Viton: 990021006


PVDA8
Düşük Geçirgenlik
0-150 lpm
