Note: Data may vary by configuration. See CONFIGURATION section.
Cavity |
T-11A |
Series |
1 |
Capacity |
15 gpm60 L/min. |
Maximum Operating Pressure |
5000 psi350 bar |
Factory Pressure Settings Established at |
Kick down pointKick down point |
Maximum Valve Leakage at 110 SUS (24 cSt) |
2 in³/min.30 cc/min. |
Response Time - Typical |
25 ms25 ms |
Adjustment - No. of CW Turns from Min. to Max. setting |
55 |
Valve Hex Size |
7/8 in.22,2 mm |
Valve Installation Torque |
30 - 35 lbf ft41 - 47 Nm |
Adjustment Screw Internal Hex Size |
5/32 in.4 mm |
Locknut Hex Size |
9/16 in.15 mm |
Locknut Torque |
80 - 90 lbf in.9 - 10 Nm |
Model Weight |
.40 lb0,20 kg |
Seal kit - Cartridge |
Buna: 990011007 |
Seal kit - Cartridge |
Polyurethane: 990011002 |
Seal kit - Cartridge |
Viton: 990011006 |
