RSHEBBN Air-controlled, pilot-operated, balanced piston sequence valve

RSHEBBN Air-controlled, pilot-operated, balanced piston sequence valve

Price : $330.01
:
Add to Favorites
Add to My Wish List
Compare
Notify me when the price goes down
Notify me when it is in stock
Recommend
Write a comment
RSHE

Note: Data may vary by configuration. See CONFIGURATION section.
Cavity T-17A
Series 3
Capacity 60 gpm240 L/min.
Maximum Operating Pressure 2000 psi140 bar
Pilot Ratio 20:120:1
Factory Pressure Settings Established at 4 gpm15 L/min.
Maximum Valve Leakage at 110 SUS (24 cSt) 4 in³/min.65 cc/min.
Maximum Air Pressure 150 psi10,5 bar
Response Time - Typical 10 ms10 ms
Valve Hex Size 1 1/4 in.31,8 mm
Valve Installation Torque 150 - 160 lbf ft203 - 217 Nm
Model Weight 1.50 lb0,70 kg
Seal kit - Cartridge Buna: 990017007
Seal kit - Cartridge Polyurethane: 990017002
Seal kit - Cartridge Viton: 990017006
Back to Top


RSHE
Medium Flow Rate
150-300 lpm
