PPJCBBN Air-controlled, pilot-operated, pressure reducing/relieving valve

PPJCBBN Air-controlled, pilot-operated, pressure reducing/relieving valve

Price : $799.92
:
Add to Favorites
Add to My Wish List
Compare
Notify me when the price goes down
Notify me when it is in stock
Recommend
Write a comment
PPJC

Note: Data may vary by configuration. See CONFIGURATION section.
Cavity T-19A
Series 4
Capacity 80 gpm320 L/min.
Maximum Operating Pressure 2000 psi140 bar
Pilot Ratio 20:120:1
Control Pilot Flow 15 - 20 in³/min.0,25 - 0,33 L/min.
Maximum Air Pressure 150 psi10,5 bar
Valve Hex Size 1 5/8 in.41,3 mm
Valve Installation Torque 350 - 375 lbf ft474 - 508 Nm
Locknut Hex Size 9/16 in.15 mm
Locknut Torque 80 - 90 lbf in.9 - 10 Nm
Model Weight 3.10 lb1,40 kg
Seal kit - Cartridge Buna: 990019007
Seal kit - Cartridge Polyurethane: 990019002
Seal kit - Cartridge Viton: 990019006
Back to Top


PPJC
High Flow Rate
300-1000 lpm
