PPFCABN Air-controlled, pilot-operated, pressure reducing/relieving valve

PPFCABN Air-controlled, pilot-operated, pressure reducing/relieving valve

Price : $244.37
:
Add to Favorites
Add to My Wish List
Compare
Notify me when the price goes down
Notify me when it is in stock
Recommend
Write a comment
PPFC

Note: Data may vary by configuration. See CONFIGURATION section.
Cavity T-2A
Series 2
Capacity 20 gpm80 L/min.
Maximum Operating Pressure 2000 psi140 bar
Pilot Ratio 20:120:1
Control Pilot Flow 10 - 15 in³/min.0,16 - 0,25 L/min.
Maximum Air Pressure 150 psi10,5 bar
Valve Hex Size 1 1/8 in.28,6 mm
Valve Installation Torque 45 - 50 lbf ft61 - 68 Nm
Adjustment Screw Internal Hex Size 5/32 in.4 mm
Locknut Hex Size 9/16 in.15 mm
Locknut Torque 80 - 90 lbf in.9 - 10 Nm
Model Weight .50 lb0,25 kg
Seal kit - Cartridge Buna: 990202007
Seal kit - Cartridge Polyurethane: 990002002
Seal kit - Cartridge Viton: 990202006
Back to Top


PPFC
Low Flow Rate
0-150 lpm
