Note: Data may vary by configuration. See CONFIGURATION section.
| Cavity |
T-21A |
| Series |
1 |
| Capacity |
10 gpm40 L/min. |
| Maximum Operating Pressure |
5000 psi350 bar |
| Factory Pressure Settings Established at |
4 gpm15 L/min. |
| Maximum Valve Leakage at 110 SUS (24 cSt) |
2 in³/min.@1000 psi30 cc/min.@70 bar |
| Check Cracking Pressure |
25 psi1,7 bar |
| Pilot Control Cavity |
T-8AT-8A |
| Pilot Control Valve Installation Torque |
20 - 25 lbf ft27 - 33 Nm |
| Response Time - Typical |
10 ms10 ms |
| Valve Hex Size |
7/8 in.22,2 mm |
| Valve Installation Torque |
30 - 35 lbf ft41 - 47 Nm |
| Seal kit - Cartridge |
Buna: 990021007 |
| Seal kit - Cartridge |
EPDM: 990021014 |
| Seal kit - Cartridge |
Polyurethane: 990021002 |
| Seal kit - Cartridge |
Viton: 990021006 |
