Note: Data may vary by configuration. See CONFIGURATION section.
Cavity |
T-34A |
Series |
4 |
Capacity |
12 - 60 gpm45 - 240 L/min. |
Maximum Operating Pressure |
5000 psi350 bar |
Divisional Accuracy at Minimum Input Flow |
50% ±4.5%50% ±4.5% |
Divisional Accuracy at Max Input Flow |
50% ±2.5%50% ±2.5% |
Pressure Drop at Minimum Rated Input Flow |
30 psi2 bar |
Pressure Drop at Maximum Rated Input Flow |
350 psi24 bar |
Valve Hex Size |
1 5/8 in.41,3 mm |
Valve Installation Torque |
350 - 375 lbf ft474 - 508 Nm |
Model Weight |
2.80 lb1,30 kg |
Seal kit - Cartridge |
Buna: 990034007 |
Seal kit - Cartridge |
Polyurethane: 990034002 |
Seal kit - Cartridge |
Viton: 990034006 |
