Note: Data may vary by configuration. See CONFIGURATION section.
Cavity |
T-13A |
Series |
1 |
Capacity |
20 gpm80 L/min. |
Maximum Operating Pressure |
5000 psi350 bar |
Maximum Valve Leakage at 110 SUS (24 cSt) |
1 drops/min.0,07 cc/min. |
Valve Hex Size |
7/8 in.22,2 mm |
Valve Installation Torque |
30 - 35 lbf ft41 - 47 Nm |
Model Weight |
.20 lb0,10 kg |
Seal kit - Cartridge |
Buna: 990010007 |
Seal kit - Cartridge |
EPDM: 990010014 |
Seal kit - Cartridge |
Polyurethane: 990010002 |
Seal kit - Cartridge |
Viton: 990010006 |
